Color: black, white Input: 100-240V, 50/60Hz, 2.5A Output: 24V 8A AC Inlet: C6, C8, C14 Efficiency: Level VI Certification: UL, FCC, CE, UKCA, SAA, KC, CB, CCC, RoHS, PSE
The 24V 8A Medical power adapter is a high-performance 192W AC/DC power supply designed for medical equipment, laboratory instruments, healthcare devices, and industrial applications. Certified to UL 60601-1, CB, and NOM standards, this medical-grade power adapter provides reliable performance, low leakage current, and enhanced safety protection for critical applications.
Featuring universal 100-240VAC input and high energy efficiency, this 24V 8A power adapter is suitable for global markets and supports OEM and ODM customization requirements.
Key Features
• 24V DC Output, 8A Current, 192W Maximum Power
• UL 60601-1, CB and NOM Certified Medical Power Adapter
• Universal 100-240VAC Input for Worldwide Applications
• Low Leakage Current Design for Medical Equipment
• High Efficiency and Stable Performance
• OVP, OCP, SCP and OTP Protection Functions
• Class I and Class II Versions Available
• Multiple AC Plug and DC Connector Options
• OEM & ODM Customization Supported
• 100% Full Load Aging Test Before Shipment
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage | 100-240VAC |
| Input Frequency | 50/60Hz |
| Output Voltage | 24V DC |
| Output Current | 8A |
| Output Power | 192W |
| Efficiency | Level VI |
| Safety Standard | IEC/UL 60601, 62368 optional |
| Certifications | UL, CB, NOM, CE |
| Protection | OVP/OCP/SCP/OTP |
| DC Cable | 1.5m, 1.8m, etc |
| Warranty | 2 Years |
| DC Connector | 5.5*2.5mm, 5.5*2.1mm, etc |
Request a Free Quote Today
Need a UL 60601 certified 24V 8A Medical Power Adapter for your medical equipment or industrial application?
Mingxin Power offers high-quality AC/DC power adapters with global certifications, flexible OEM/ODM services, and fast production support. Our team can help you select the right power solution based on your voltage, current, connector, and compliance requirements.
Send us email (ellen@mingxinpower.com) about your requirements today and receive a fast quotation, technical consultation, and sample support from our professional team.
